Design floating life @ 20°C (68°F)

5 years

Nominal capacity @ 25°C / 77°F (20 hr rate)

1.2 Ah (0.06A to 1.75Vpc)

Nominal capacity @ 25°C / 77°F (10 hr rate)

1.1 Ah (0.11A to 1.75Vpc)

Nominal capacity @ 25°C / 77°F (5 hr rate)

1.05 Ah (0.21A to 1.70Vpc)

Nominal capacity @ 25°C / 77°F (1 hr rate)

0.65 Ah (0.65A to 1.60Vpc)

Internal resistance (fully charged @ 25°C / 77°F)

120 mΩ

Max discharge current @ 25°C / 77°F

18 A (5 sec)

Cycle use voltage

14.7 – 14.9 V

Max charging current

0.3 A

Standby use voltage

13.6 – 13.8 V

Operating temperature (discharge)

-15 ~ 35°C

Operating temperature (charge)

0 ~ 35°C

Operating temperature (storage)

-15 ~ 35°C

Recommended operating temperature

15 ~ 25°C

Self-discharge

~3% capacity loss per month @ 20°C; up to 6 months storage @ 25°C (freshening charge required after)

Dimensions (L × W × H)

97.5 × 43.5 × 53 mm (3.8 × 1.7 × 2.1 in)

Total height

57 mm (2.2 in)

Weight

0.49 kg (1.08 lbs)

Terminal type

T1
